Hosyond 4 inch
The ESP32-32E E32R40T: 4 inch, 480 × 320, sold as a 4-inch "CYD".
| Tiles per page | 6 lying down (2 × 3), 4 standing up (1 × 4) |
| Touch | Resistive, with a calibration on the first start |
| Backlight | Dims; standby and night mode |
| Pictures | No |
| Screensaver | The clock |
| Flash | 4 MB; see Screens with 4 MB of flash |
| Status | Experimental |
Buying
The model with touch is E32R40T. The E32N40T is the same board without touch: don't buy that one.
Good to know
- It behaves like the CYD: a calibration on the first start, no hotspot, no pictures, the clock as screensaver.
- Not yet tried on real hardware by the project: colours, mirroring and touch axes may need a line in Override YAML. Please report.
