Bluetooth proxy plugin preview

Bluetooth proxy

Home Assistant reaches Bluetooth devices near the screen. Shares the radio with Wi-Fi.

By MaxGramser · v0.2.0

Needs bluetooth on the screen.

View on GitHub How to add a plugin
No rating yetRatings come from people who run it, in the Tessera app
0people like it, some without running it
0homes use it, of those who share that

Turns the screen into a Bluetooth proxy for Home Assistant, the same one a ready-made ESPHome Bluetooth proxy runs. Home Assistant then hears Bluetooth devices near the screen (thermometers, plant sensors, tags for presence with Bermuda) and can connect to some of them through it (a lock, a light), up to three at a time.

Before you add it: Wi-Fi

The screen does Wi-Fi and Bluetooth with one radio, so every moment it listens for Bluetooth is a moment without Wi-Fi. The plugin listens the way ESPHome's own Wi-Fi proxies do, a short slice of time at a steady pace, but the screen still has less Wi-Fi than before:

  • Pictures, covers and camera streams can load more slowly. One tester saw a camera stream run clearly smoother with the proxy off.
  • On weak Wi-Fi the screen can react more slowly to Home Assistant, or drop its connection more often.

Turn the proxy off at any time with the setting Bluetooth proxy (below), without a build. When the screen shows camera streams, or hangs on the edge of your Wi-Fi, a separate ESP32 as a Bluetooth proxy is the better choice: it costs a few euros and you can put it where the reception is best.

Which screens

Every screen with an ESP32-P4 (the Guition P4 screens, the Waveshare P4 86, the M5Stack Tab5, the reTerminal D1001, the CrowPanel 10.1). The P4 runs Bluetooth through the ESP32-C6 beside it, which also does its Wi-Fi, and has the memory to spare. The app only offers the plugin on those screens.

Not on an ESP32-S3 with an RGB panel (the 4-inch Guition, the Waveshare 4.3, 5 and 7-inch, and their kind): Bluetooth needs memory inside the chip that the panel and Wi-Fi already use, and such a screen stops connecting. Not on the CYD and other 4 MB screens either: there is no room for it.

What you need

  • A screen with an ESP32-P4.
  • A recent firmware on its ESP32-C6, the chip beside the P4 that does Wi-Fi and Bluetooth. Many screens come with one too old for Bluetooth (a reTerminal D1001 came with 2.3.2). The plugin brings the update with it, see "Updating the C6" below. With the old firmware the screen works as before and Bluetooth stays off.

Set up

  1. In Tessera, open Plugins, choose Bluetooth proxy and tick your screen. Leave Wi-Fi chip update ticked.
  2. Add it. The screen builds once.
  3. In Home Assistant, open the screen's device. Bluetooth status says what the proxy does. Listening: done. Update the Wi-Fi chip: the C6 firmware is too old, follow "Updating the C6" below.
  4. In Home Assistant, Settings, Devices & services, Bluetooth shows the screen as a proxy, named after the screen and the Bluetooth address of its C6 (not the Wi-Fi address of the screen), and the devices it hears as Home Assistant finds them.

On the screen and in the app

Bluetooth proxy turns Bluetooth on and off, and Bluetooth status says what it does: listening, off, starting, or that the Wi-Fi chip needs its update. Both are in Home Assistant on the screen's device, and on the screen itself: hold the top bar, then Settings, Plugins, Bluetooth. The switch is also in the plugin's details on the screen's Plugins tab in Tessera. Off gives the radio to Wi-Fi alone; the screen keeps it off across a restart until you turn it on.

Updating the C6

The ESP32-C6 has a firmware of its own, and ESPHome publishes newer ones. With Wi-Fi chip update ticked, the screen's device in Home Assistant has Wi-Fi co-processor firmware, with the version on the C6 and the newest one. It never installs by itself: an update that goes wrong leaves the C6 starting over and over, and only its download mode brings it back, which on some screens means opening the case. So it waits for you:

  1. In Home Assistant, open the screen's device and Wi-Fi co-processor firmware.
  2. Press Install, and leave the screen powered until it is done (a few minutes). The screen restarts, and Bluetooth status says Listening.

It checks for a newer version every six hours and shows it there; installing stays your choice. Do not want it? Untick Wi-Fi chip update in the plugin's details on the screen's Plugins tab and choose Save and build.

Good to know

  • It adds about 370 KB to the firmware, and the Wi-Fi chip update about 200 KB more. Every P4 screen has room for that.
  • The proxy follows ESPHome's own: what Home Assistant does with it is in the ESPHome Bluetooth proxy docs.
  • Added a Bluetooth proxy or the C6 update through the screen's Override YAML before? Remove those blocks (esp32_ble_tracker:, bluetooth_proxy:, http_request: and the esp32_hosted update) first, or the build finds them twice. The update keeps its name, so Home Assistant keeps its entity. If that entity says unavailable after the build, reload the screen in Home Assistant (Settings, Devices & services, ESPHome, the screen's three dots, Reload).
  • Tried on a reTerminal D1001: its C6 went from 2.3.2 to 2.12.12 with Install, and the proxy heard 51 devices in its first minute. With 0.2.0, built by the Tessera app from the plugin with Wi-Fi chip update, the screen shows Bluetooth status Listening and the update as up to date.
